Air Carbon Arc Gouging Welding Equipment & Supplies

Air carbon arc gouging is a process of removing metal by means of heat generated from a carbon arc. The process uses a carbon/graphite electrode, compressed air and a standard power source. The intense electric arc used between the tip of a carbon electrode and a metal work piece cuts and melts the work piece. The arc is initiated by striking the electrode tip on the surface of the work piece. Then compressed air is used for blowing the molten metal thoroughly from the metal surface. The metal is only cut or gouged along the airflow direction. This process is simple to apply. The main purpose is to remove defective or old welds in order to repair or dismantle equipment.

Required equipment includes an air compressor, welding power source, carbon electrode and a gouging torch.

Guns & Torches

  • Tweco K4000 Arc Gouging Torch
  • Tweco K5000 Arc Gouging Torch
  • Complete line of Tweco replacement parts

Holders & Ground Clamps

  • Anchor Electrode Holders
  • Tweco Electrode Holders
  • Anchor Ground Clamps
  • Tweco Ground Clamps

Carbons

  • Tweco Arcair Gouging Electrodes
  • Tweco Arcair Jetrods
  • Victor Arcair Gouging Electrodes

Browse our complete of Arc & Gouging equipment and order online.

When choosing a welder, it is important to understand the basic welding processes and their uses. The four basic welding processes are listed below.

MIG Welding

MIG Welding, also known as Gas Metal Arc Welding (GMAW), is a process developed in the 1940’s that is considered semi-automatic and requires electricity to produce heat, an electrode to fill the joint and a shielding gas to protect the weld from the air. A MIG welder utilizes a constant DC current while wire and gas are fed continuously through the welding gun and leads as the gun’s trigger is depressed. It is most commonly used in fabrication environments where production needs are high.

Common shielding gases include:
  • Argon
  • Carbon Dioxide
  • 75/25 Mixed Gas
  • Helium

TIG Welding

TIG Welding, also known as Gas Tungsten Arc Welding (GTAW), is a manual welding process that requires the welder to use two hands. One hand holds the TIG torch that produces the arc and the other hand is used to add the filler metal to the weld joint. TIG Welding is the most difficult process to learn but is the most versatile. When done correctly, TIG Welding produces the highest quality weld. It is heavily utilized for critical weld joints, welding metals other than common steel and for where precise, small welds are required.

Common shielding gases include:
  • Argon
  • Helium
  • Ar/He Mix

Stick Welding

Stick Welding, also known as Shielded Metal Arc Welding (SMAW), is a manual process that is often used in high wind outdoor repair situations. It utilizes a power source connected to an electrode holder. Current passes through the leads to the electrode. Shielding gas is not needed for this process because the electrode is covered in flux which protects the arc during a weld.

Flux Cored Welding

Flux Cored Arc Welding (FCAW) is very similar to MIG welding. The main difference is the filler metal is hollow and filled with flux, so a shielding gas is not required for this process. Flux cored welding is often used in high wind outdoor repair situations.
